NOK_BRT2_BRT3铁氟龙支撑环垫片

特点：19YF/31BF开口&不开口、防止密封件的挤压、提高耐压性

适用主要流体：

通用石油基液压油

水乙二醇液压油

油-水乳化型液压油

磷酸酯液压油

低温石油基液压油

标准切割形状：斜切 (BRT2)


0

产品规格

规格部品番号
BRT2BRT3
8*18*2GN4773V0GN0725V0
10*20*2GN4774V0GN0733V0
14*24*2GN4775V0GN0745V0
15*28*2GN4776V0GN6445V0
16*26*2GN4777V0GN0751V0
18*26*2GN4778V0GN6377V0
18*31*2GN4779V0GN6446V0
20*28*2GN4780V0GN6447V0
20*30*2GN4781V0GN0762V0
20*33*2GN4782V0GN6448V0
22*35*2GN4783V0GN6449V0
22.4*30*2GN4784V0GN6450V0
22.4*33*2GN4785V0GN6451V0
23.5*31.5*2GN4786V0GN6452V0
25*35*2GN4787V0GN0781V0
25*38*2GN4788V0GN6453V0
25.5*35.5*2GN4789V0GN6454V0
27*40*3GN4790V0GN6455V0
28*35.5*3GN4791V0GN6456V0
28*40*3GN4792V0GN6457V0
28*41*3GN4793V0GN6458V0
30*40*3GN4794V0GN6361V0
30*43*3GN4795V0GN6459V0
31.5*41.5*3GN4796V0GN6460V0
31.5*44.5*3GN4797V0GN6461V0
34*50*3GN4798V0GN6462V0
35*45*3GN4799V0GN6463V0
35*50*3GN4800V0GN0816V0
35.5*45*3GN4801V0GN6464V0
35.5*51.5*3GN4802V0GN6330V0
40*50*3GN4050V0GN6465V0
40*56*3GN4803V0GN6466V0
45*55*3GN4804V0GN6467V0
45*56*3GN4805V0GN6468V0
45*61*3GN4806V0GN6469V0
47*61*3GN4807V0GN6470V0
47*63*3GN4808V0GN6471V0
50*60*3GN4335V0GN6302V0
50*66*3GN4809V0GN6329V0
53*63*3GN4693V0GN6413V0
55*65*3GN4810V0GN6472V0
55*71*3GN4811V0GN6473V0
56*66*3GN4766V0GN6474V0
60*70*3GN4676V0GN6444V0
60*71*3GN4812V0GN6475V0
60*76*3GN4813V0GN6476V0
63*73*3GN4814V0GN6477V0
64*80*3GN4815V0GN6478V0
65*75*3GN4816V0GN6479V0
67*77*3GN4697V0GN6480V0
70*80*3GN4651V0GN6362V1
70*90*3GN4817V0GN0910V0
71*80*3GN4818V0GN6481V0
71*81*3GN4819V0GN6482V0
75*95*3GN4524V0GN0920V0
80*90*3GN4820V0GN6483V0
80*100*3GN4095V1GN0927V0
85*100*3GN4687V0GN6484V0



规格部品番号
BRT2BRT3
85*105*3GN4821V0GN0932V0
90*105*3GN4698V0GN6485V0
90*110*3GN4109V0GN0939V0
95*110*3GN4822V0GN6486V0
95*115*3GN4823V0GN0945V0
98*112*3GN4824V0GN6487V0
100*115*3GN4512V0GN6488V0
100*120*3GN4119V0GN0952V0
105*125*3GN4825V0GN0959V0
106*120*3GN4826V0GN6489V0
112*125*3GN4827V0GN6490V0
112*132*3GN4828V0GN0970V0
120*140*3GN4132V0GN0982V0
125*140*3GN4481V0GN6491V0
125*150*3GN4401V0GN6135V0
135*160*3GN4829V0GN6492V0
136*150*3GN4830V0GN6493V0
140*165*3GN4831V0GN6494V0
145*160*3GN4551V0GN6495V0
145*170*3GN4832V0GN6496V0
150*165*3GN4833V0GN6497V0
155*170*4GN4834V0GN6498V0
155*180*4GN4157V0GN1016V0
160*175*4GN4835V0GN6499V0
160*185*4GN4540V0GN1020V0
165*180*4GN4836V0GN6500V0
170*180*4GN4837V0GN6501V0
170*200*4GN4838V0GN6502V0
175*190*4GN4839V0GN6503V0
175*200*4GN4460V0GN1031V0
180*200*4GN4470V0GN6372V0
180*205*4GN4427V0GN1035V0
190*200*4GN4840V0GN6504V0
190*210*4GN4841V0GN6505V0
200*220*4GN4385V0GN6276V0
200*225*4GN4560V0GN1050V0
204*224*4GN4842V0GN6506V0
205*220*4GN4843V0GN6507V0
210*230*4GN4627V0GN6352V0
220*240*4GN4444V0GN6508V0
225*245*4GN4844V0GN6509V0
225*250*4GN4416V0GN1065V0
230*250*4GN4635V0GN6510V0
240*260*4GN4845V0GN6511V0
250*270*4GN4459V0GN6512V0
250*275*4GN4191V0GN1078V0
255*280*4GN4846V0GN6513V0
260*285*4GN4847V0GN6514V0
265*290*4GN4848V0GN6318V0
265*297*4GN4849V0GN6515V0
270*295*4GN4850V0GN6516V0
270*300*4GN4851V0GN1089V0
275*300*4GN4852V0GN6517V0
280*305*4GN4410V0GN6518V0
280*312*4GN4853V0GN6519V0
290*315*4GN4854V0GN6520V0
300*325*4GN4855V0GN6521V0
300*332*4GN4856V0GN6522V0
